Hello-I have an 8-relay serial I/O controller board I would like to use in a project (Kitsrus Model K108). This unit was designed to run off a PC via the serial port, and control the relays via simple text commands (ie 'N1' for relay 1 on, 'F1' for relay 1 off, and so on). It is not stand-alone programmable.I recently began working with the BS2, and would like to use it, as an embedded controller hooked up to the K108 I/O board in a project to control a series of 100W floodlights.I have been trying to use the SEROUT command, with a straight through cable connected from the BOE 9-pin, to the 9-pin on the K108. That should be easy.

I'm betting that your baud rate setting is not correct. Use the attached template for your tests - it allows you to set the baud rate based on the BASIC Stamp module that you're using; it also allows you to select True (which is what you need, I believe) or Inverted very easily.Using this template you should have a Baud definition like this:Baud CON T9600If I'm wrong and you need inverted mode, change the definition to this:Baud CON T9600 + Inverted▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔▔Jon WilliamsApplications Engineer, ParallaxDallas, TX USA.

Overview:Red Lion's Sixnet series EtherTRAK®-2 Ethernet enabled I/O modules provide simple and secure remote monitoring for deployments in harsh environments. EtherTRAK-2 offers a low cost per I/O point and rugged environmental ratings for reliable sensor or field data collection and communication.Connectivity:The EtherTRAK-2 I/O modules offer dual Ethernet ports providing network expandability or redundancy functionality supporting TCP/IP, ARP, UDP, ICMP, DHCP, HTTP, Modbus UDP/TCP Slave mode, Modbus UDP Master mode, Sixnet UDR UDP/TCP Slave mode, and Sixnet UDR UDP Master mode. Additionally, built-in security helps prevent unauthorized users with permission-level access and Firewall protection.

The EtherTRAK-2 modules also offer RS-485 serial connectivity and USB connectors for easy management and communication to deployed assets.Performance:The E2/EB line of EtherTRAK I/O modules provide uncompromising performance in harsh environments. The EtherTRAK modules accept 10-30 VDC power input (24 VDC nominal).Environmental:Sixnet's EtherTRAK-2 I/O modules are designed and built for harsh environments. With -40° to 75°C operating temperatures, UL Class I, Division 2 Group A, B, C, D listings, CSA, ATEX Zone 2, ABS, DNV, and Lloyds certified. With built-in self-resetting fuses the EthernTRAK-2 will provide years of reliable operation in any industrial environment. About UsAs global experts in communication, monitoring and control for industrial automation and networking, Red Lion has been delivering innovative solutions for over forty years. Our automation, Ethernet and cellular M2M technology enables companies worldwide to gain real-time data visibility that drives productivity. Product brands include Red Lion, N-Tron and Sixnet.
